RACING ATF (TYPE F)

Specifically for drag racing, this is the most viscous ATF that we make and it isn't slippery.

Watch
the video
RACING ATF - QUART
  • Similar to a Type F fluid, featuring even higher viscosity and no friction modifiers
  • Produces faster shifts, quicker lock-up, better converter efficiency at high temps
  • Enhanced extreme-pressure additives provide 5-times better film strength than petroleum ATFs
  • Reduced clutch and gear wear compared to petroleum ATFs
FEATURED RETAILERS

With eight different combinations of viscosity, slipperiness, and OE-recommended additives packages, Red Line offers the widest selection of ATF available

  • Red Line offers the widest selection of fully-synthetic ATF on the market today
  • Each offer improved thermal stability, maintain viscosity levels, and feature lower volatility while providing the required frictional characteristics of each fluid's OEM-style replacement
  • Reduced oxidation and lower volatility at high temperature
  • Allows high-temp operation without varnishing valves and clutches
  • Extended drain intervals

DATA SHEET DOWNLOADS

Safety Data Sheets Product Data Sheets

TYPICAL PROPERTIES

Vis @ 100°C, CSt 10
Vis @ 40°C, CSt 53.7
Viscosity Index 177
Pour Point, °C -50
Pour Point, °F -58
Brookfield Viscosity @ -40°C, Poise 150

AVAILABLE SIZES

Quart 30304
Gallon 30305
5 Gallon* 30306
16 Gallon* 30307
55 Gallon* 30308

Red Line's Racing ATF is full-synthetic product designed for use in racing automatic transmissions which need the positive shift of a Type F automatic transmission fluid. This ATF contains no slipperiness additives, producing faster shifts and quicker lock-up, and can reduce elapsed time in drag racing.

A higher viscosity compared to conventional Type-F transmission fluids provides higher torque converter efficiency at higher temperatures. The enhanced extreme-pressure protection provides five-times better film strength when compared to petroleum ATFs, reducing gear and clutch wear considerably.

This product is designed to be used where Type-F fluids are recommended or for racing transmissions which need quicker shifts than provided with Dexron II fluids. This product can also be used in manual transmissions which require ATFs, providing better gear wear and better shiftability, but Red Line MTL® will provide even better wear protection and shiftability.

Suitable Replacement for:

Chrysler TF727
Ford Type F
Ford M2C33F
GM TH350
GM TH400
Lenco/B&J Planetary Trans
Powerglide
